42BYGHW811 Stepper Motor (2.5 A, 4.8 kg⋅cm)

Please allow 4-6 days processing before ship out. For gearmotors or similar motors, we don’t ship using epacket and will use regular shipping if needed. Please note that regular shipping like singapore post might take 45-60 days to deliver, epacket 20 -35 days to deliver Thank you for understanding. » Stepper Motors » 42BYGHW811 Stepper Motor (2.5 A, 4.8 kg⋅cm)

42BYGHW811 Stepper Motor (2.5 A, 4.8 kg⋅cm)

The 42BYGHW811 stepper motor is suitable for use with CNC or 3D printers.

SKU: WTM7431616976

Overview

The 42BYGHW811 stepper motor is suitable for use with CNC or 3D printers.

Specifications

Step accuracy: ±5%
Ambient temperature range: 20°C ~ 50°C
Insulation resistance: 100MΩ Min.50V DC
Dielectric strength: 500V AC for 1 minute
Step angle: 1.8°
Voltage rating: 3.1 V
Current rating: 2.5 A
Resistance: 1.25 Ω per coil
Inductance: 1.8 mH
Temperature rise tolerance: 80°C
Holding torque: 4800 g⋅cm
Detent torque: 280 g⋅cm
Rotor inertia: 68 g⋅c㎡
Number of leads: 4
Motor length : 4.8 cm
Weight: 340 g

Downloads

42BYGHW811 Stepper Motor Datasheet.pdf
