42BYGH801 Stepper Motor (0.4 A, 3.8 kg⋅cm)

Please allow 4-6 days processing before ship out. For gearmotors or similar motors, we don’t ship using epacket and will use regular shipping if needed. Please note that regular shipping like singapore post might take 45-60 days to deliver, epacket 20 -35 days to deliver Thank you for understanding. » Stepper Motors » 42BYGH801 Stepper Motor (0.4 A, 3.8 kg⋅cm)

42BYGH801 Stepper Motor (0.4 A, 3.8 kg⋅cm)

This 42BYGH801 stepper motor is simple but powerful. It is reliable and it makes a great choice for a wide range of projects.

SKU: WTM7430996438

Overview

This 42BYGH801 stepper motor is simple but powerful. It is reliable and it makes a great choice for a wide range of projects.

Specifications

Step accuracy: ±5%
Ambient temperature range: 20°C ~ 50°C
Insulation resistance: 100MΩ Min.50V DC
Dielectric strength: 500V AC for 1 minute
Step angle: 1.8°
Voltage rating: 12 V
Current rating: 0.4 A
Resistance: 30 Ω per coil
Inductance: 28 mH per coil
Temperature rise tolerance: 80°C
Holding torque: 3800 g⋅cm
Detent torque: 280 g⋅cm
Rotor inertia: 34 g⋅c㎡
Number of leads: 6
Motor length : 4.8 cm
Weight: 340 g

Downloads

42BYGH801 Stepper Motor Datasheet.pdf
