L298P Dual Motor Driver Shield SMD with Buzzer

L298P Dual Motor Driver Shield SMD with Buzzer
This L298P dual motor driver shield uses a high power motor driver chip L298P to drive 2 DC motors and drive current up to 2A. The motor output uses 8 high-speed Schottky diode as a protection and can be directly inserted to your Arduino projects.

SKU: WUM521260002596

Price: 5.07 $

Old Price: 6.92 $

Product in stock

SSL Certificate
Quantity
Loading Updating cart...

Overview

This L298P dual motor driver shield uses a high power motor driver chip L298P to drive 2 DC motors and drive current up to 2A. The motor output uses 8 high-speed Schottky diode as a protection and can be directly inserted to your Arduino projects.

The product is compatible with Arduino development board and uses D10 - D13 digital pins. The module also contains a buzzer connected to terminal D4.

The module is recommended for beginners and can be used to control two motors simultaneously or a single stepper motor. The driver can control small to medium power motors, supporting a maximum of 2A. Shield offers many additional connections and contains diodes to protect the driver.

Specifications:

  • Supply Voltage: 5 V
  • VIN Voltage: 6.5 V to 12 V
  • PWRIN Voltage: 4.8 V to 35 V
  • Required logic current: 36 mA (max)
  • Maximum motor current: 2 A / motor
  • Maximum power dissipation: 25 W
  • Size: 65 x 53mm
