SI4463 RF Transceiver (868 MHz)
SI4463 RF transceiver (868 MHz) is useful for long-distance communications.

SKU: OTH521212424200

Price: 9.40 $

Product in stock

SSL Certificate
Quantity
Loading Updating cart...

Overview

This product is a useful SI4463 RF transceiver for data transmission over long distances with lower power consumption. The trend lately sent to new technology that adapts to little monitoring and data transmission over long distances.

The module can be used for point to point communications, such as controlling a vineyard by measuring various parameters in several areas (humidity, soil acidity, temperature).

Specifications

  • Data Transmission Frequency: 868 MHz
  • Voltage: 2.1 V to 5.5 V
  • Max. data transmission distance in open field: 2000m (with 5dBi gain antenna, at the rate of 1 kbps to 2 meters tall)
  • Max. Transmission Power: 20 dBm to 100 mW
  • Data Transfer Rate: configurable from 1, 2, 5, 8, 19, 15, 20, 25 kbps
  • Standby Current: 2.0 uA
  • Power transmission at max. power: 90 mA
  • Current Reception: 17 mA
  • Sensitivity: -121 dBm @ 1kbps
  • Dimensions: 21 x 36 mm (without antenna socket)

Operating modes:

Mode M1 M0
Mod 0 - normal 0 0
Mode 1 - wake-up 0 1
Mode 2 - power saving 1 0
Mode 3 - Sleep 1 1
